Case: Bone & joint disease radiograph #131783827
Bone & joint disease Intermediate
Read this radiograph systematically before revealing the answer. What is the main abnormality?
Image: Hellerhoff via Wikimedia Commons · CC BY-SA 4.0 · source · resized and converted to WebP
Tip: scroll or pinch to zoom, drag to pan, and try Invert.
Answer: Heterotopic ossification
What to look for in heterotopic ossification
- Mature bone forming in soft tissues, often around the hip after surgery or trauma, or after neurological injury.
- Matures from the periphery inwards, giving a well-defined cortical rim (compare with the central ossification of osteosarcoma).
- Separate from the underlying bone or only loosely attached.
Description by the image author (may be in another language): Heterotope Ossifikationen nach Implantation einer Hüftendoprothese: Links postoperatives Bild nach der Implantation; rechts 2 Jahre später.
Educational case. The diagnosis comes from the image's documented source; the "what to look for" list describes the condition in general and is not a report of this individual image.
