Before you look for disease, decide whether the film is good enough to answer the question. Poor technique is one of the commonest causes of false positives on chest radiographs: a rotated film invents a hilar mass, a poor breath invents basal shadowing, and an under-exposed film invents consolidation behind the heart. Poor technique also hides real disease. The RIPE mnemonic gives you four quick checks: Rotation, Inspiration, Projection and Exposure. Add a check of coverage, and you will know how much weight to put on what you see.

1. Pre-checks before RIPE

• Patient identity: name and a second identifier, such as date of birth or hospital number.
• Date and time: especially important on ICU, where several films may be taken in a day.
• Previous imaging: find it now. Comparison will answer many quality questions (is that hilum always prominent?).
• Labels and markers: side marker, and any annotation such as "AP", "supine", "erect" or "mobile".

2. R: Rotation

How to check: find the medial ends of both clavicles and the spinous process of the vertebra between them. On a straight film, the spinous process sits midway between the two clavicular heads.

Why it matters: rotation shifts the mediastinum on the film. It can make one hilum look larger or denser, alter the outline of the heart and aorta, and change the apparent density of each lung: the lung on one side looks blacker than the other even though both are normal. A rotated film is a common cause of a falsely "abnormal" mediastinum or an apparent unilateral hyperlucency.

3. I: Inspiration

How to check: count the ribs visible above the mid-point of the right hemidiaphragm (in the mid-clavicular line).

Posterior ribs are the more horizontal ones that join the spine; anterior ribs slope downwards and medially towards the sternum, and their anterior ends fade where they become cartilage. Counting anterior ribs is easier for most beginners; counting posterior ribs is more reproducible for some readers. Pick one method and use it consistently.

Why it matters: on a poor inspiration the lungs are small, the bronchovascular markings crowd together at the bases, and the heart and mediastinum look wider. This can mimic basal consolidation, interstitial disease and cardiomegaly. Conversely, a hyperexpanded chest with flat hemidiaphragms is itself a finding; see COPD and airways disease.

Unwell, obese, post-operative and supine patients often cannot take a full breath. That is not a reason to reject the film, but you must say that the low volumes limit assessment of the bases and heart size.

4. P: Projection

How to check: read the label, then confirm from the anatomy:

• PA: the scapulae are rotated forward and projected clear of the lungs; the clavicles are fairly horizontal and project over the apices.
• AP: the scapulae overlie the upper lungs; the clavicles project higher, often above the apices.
• Supine: often AP, with no fluid levels and a gastric bubble that may not be seen as a distinct air–fluid level.

Why it matters: the heart is magnified on AP films, so the cardiothoracic ratio (normal ≤0.5) is valid only on a PA erect adult film. Mediastinal width is magnified too. Air and fluid sit in different places on supine films. See X-ray projections for the full comparison.

5. E: Exposure (penetration)

How to check: on an adequately exposed PA chest, the thoracic vertebral bodies are just visible through the heart. You should also be able to see lung vessels behind the heart and the outline of the descending aorta.

Problem	Appearance	What it mimics or hides
Under-exposed (under-penetrated)	Too white; vertebrae not seen through the heart	Hides the retrocardiac region (where left lower lobe collapse lives) and can mimic consolidation or effusion
Over-exposed (over-penetrated)	Too dark; vertebrae very clearly seen; lung markings faint	Hides nodules and subtle consolidation; can mimic emphysema or even pneumothorax

With digital imaging you can often rescue a borderline film by adjusting window and level on the workstation. You cannot recover detail that was never captured, though, and image noise becomes obvious when you push an under-exposed image. The physics page explains kV and mAs.

6. Coverage and artefacts

RIPE says nothing about whether the whole area is included. Always check:

• Both apices are on the film (small apical pneumothoraces and Pancoast tumours sit here).
• Both costophrenic angles are included (early effusions and basal pneumothoraces).
• The lateral chest walls are included (rib fractures, surgical emphysema).
• No avoidable artefact overlies the lungs: jewellery, hair braids, clothing, ECG electrodes, oxygen tubing. Note anything that you cannot see past.
• No motion blur: blurred heart borders and diaphragm with sharp ribs suggests the patient moved or breathed during the exposure.

If an area is missing, say so in your description. "The left costophrenic angle is not included" is a legitimate and important statement.

7. Quality beyond the chest

RIPE is a chest mnemonic, but the idea that you assess adequacy first applies to every film:

• Bones and joints: at least two views at right angles; the joint above and below for long-bone injuries; the whole area of interest included. See how to describe a fracture.
• Cervical spine: the lateral view must show the skull base down to the top of T1 (the C7/T1 junction). An inadequate lateral cannot clear the spine. See cervical spine X-ray.
• Abdomen: the film should usually include from the diaphragm to the hernial orifices; larger patients may need two exposures. See how to read an abdominal X-ray.
• Lateral chest: the arms should be raised clear, and the two posterior rib outlines should be nearly superimposed. Widely separated posterior ribs suggest rotation.

8. Common pitfalls

• Reporting cardiomegaly on an AP or poor-inspiration film. Both enlarge the apparent heart.
• Calling basal shadowing on a low-volume film. Crowded vessels are not consolidation. Look for air bronchograms, a lost border or a change from a previous film.
• Diagnosing a hilar mass on a rotated film. Check the clavicles first.
• Arguing about one rib. Inspiration counts vary between sources. The purpose is to recognise a clearly poor or clearly hyperinflated film.
• Over-reading a dark film as emphysema. Check the vertebrae behind the heart and the lung markings before diagnosing hyperlucency.

Red flags: act now

What to focus on, by role

Role	Priorities
Medical student	Say RIPE aloud on every film and give a one-line verdict: "adequately rotated, inspired and penetrated" or say which is not.
Nurse	Understand why a film taken in bed may need repeating, and why a patient sitting upright and taking a deep breath gives a more useful picture.
Junior doctor	Allow for technique before calling heart size, basal shadowing or a hilar mass. Request a repeat when the urgent question cannot be answered.
Radiographer	Repeat criteria, positioning, centring, collimation and exposure. Balance the benefit of a repeat against the extra dose under IR(ME)R.
Advanced / FRCR	Recognise technique-driven pseudo-abnormalities quickly in rapid reporting, and state limitations precisely in the report.

Next: apply RIPE inside the full system in how to read a chest X-ray.
